Description
FIXED IND 100MH 90MA 76 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for 4590R-107K.
4590R-107K has an inductance value of 100 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
4590R-107K is rated for 90 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
4590R-107K lists a DC resistance of 76Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
4590R-107K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from 4590R-107K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 100 mH |
| Tolerance | ±10% |
| Current Rating | 90 mA |
| DC Resistance (DCR) | 76Ohm Max |
| Saturation Current | 60mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.455" Dia x 0.900" L (11.55mm x 22.86mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Delevan |
| Description | FIXED IND 100MH 90MA 76 OHM TH |
| Series | 4590R |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
