Description
FIXED IND 2.5UH 3.5A 52.4 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BMMA000606182R5MV1.
BMMA000606182R5MV1 has an inductance value of 2.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BMMA000606182R5MV1 is rated for 3.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BMMA000606182R5MV1 lists a DC resistance of 52.4mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BMMA000606182R5MV1 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BMMA000606182R5MV1 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 2.5 µH |
| Tolerance | ±20% |
| Current Rating | 3.5 A |
| DC Resistance (DCR) | 52.4mOhm Max |
| Saturation Current | 10.4A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.270" L x 0.255" W (6.86mm x 6.47mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.5UH 3.5A 52.4 MOHM |
| Series | BMMA |
| Product Status | Active |
| Type / Construction | Molded |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.071" (1.80mm) |
