Description
FIXED IND 2.5UH 6.1A 10.5 MOHM
Specifications
Inductance
2.5 µH
Current Rating
6.1 A
DC Resistance (DCR)
10.5mOhm Max
Dimensions
0.398" L x 0.394" W (10.10mm x 10.00mm)
Product Attributes
Manufacturer Verified
Last verified: 6/18/2026| Inductance | 2.5 µH |
| Tolerance | ±30% |
| Current Rating | 6.1 A |
| DC Resistance (DCR) | 10.5mOhm Max |
| saturationCurrent | 7.5A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.5UH 6.1A 10.5 MOHM |
| Series | BPRR |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.161" (4.10mm) |
| features | - |
