Description
FIXED IND 120NH 10.7 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CT1812SMSF-R12J.
CT1812SMSF-R12J has an inductance value of 120 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CT1812SMSF-R12J is rated for 2.2 A Max. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CT1812SMSF-R12J lists a DC resistance of 10.7mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
Explore Related Datasheet Paths
Continue from CT1812SMSF-R12J to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 120 nH |
| Tolerance | ±5% |
| Current Rating | 2.2 A Max |
| DC Resistance (DCR) | 10.7mOhm |
| Operating Temperature | -40°C ~ 85°C |
| Supplier | Central Technologies |
| Description | FIXED IND 120NH 10.7 MOHM SMD |
| Series | ct1812smsf |
| Product Status | Active |
| Type / Construction | Wirewound |
| Self Resonant Frequency | 1.1MHz |
| Mounting Type | Surface Mount |
