Description
FIXED IND 33NH 200MA 800 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L0402C33NJRMST.
L0402C33NJRMST has an inductance value of 33 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L0402C33NJRMST is rated for 200 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L0402C33NJRMST lists a DC resistance of 800mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L0402C33NJRMST uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0402C33NJRMST to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 nH |
| Tolerance | ±5% |
| Current Rating | 200 mA |
| DC Resistance (DCR) | 800mOhm |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 33NH 200MA 800 MOHM |
| Series | L-RMS |
| Product Status | Obsolete |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 11 @ 100MHz |
| Self Resonant Frequency | 1.3GHz |
| Inductance Test Frequency | 100 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 (1005 Metric) |
| Height - Seated (Max) | 0.022" (0.55mm) |
