Description
FIXED IND 10UH 205MA 1 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L0805C100MDWLT.
L0805C100MDWLT has an inductance value of 10 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L0805C100MDWLT is rated for 205 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L0805C100MDWLT lists a DC resistance of 1Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L0805C100MDWLT uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0805C100MDWLT to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 10 µH |
| Tolerance | ±20% |
| Current Rating | 205 mA |
| DC Resistance (DCR) | 1Ohm |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.083" L x 0.059" W (2.11mm x 1.50mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 10UH 205MA 1 OHM SMD |
| Series | L-DWL |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | 32MHz |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 (2012 Metric) |
| Height - Seated (Max) | 0.041" (1.04mm) |
| Features | - |
