Description
FIXED IND 33UH 85MA 1.7 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L0806C330MPWST.
L0806C330MPWST has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L0806C330MPWST is rated for 85 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L0806C330MPWST lists a DC resistance of 1.7Ohm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L0806C330MPWST uses a package or case of 0806 (2016 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0806C330MPWST to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating | 85 mA |
| DC Resistance (DCR) | 1.7Ohm |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Case / Size | 0806 (2016 Metric) |
| Package / Case | 0806 (2016 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 33UH 85MA 1.7 OHM SMD |
| Series | L-PWS |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Self Resonant Frequency | 14MHz |
| Inductance Test Frequency | 2.52 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0806 |
| Height - Seated (Max) | 0.071" (1.80mm) |
