Description
FIXED IND 1.5UH 860MA 70 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L1207C1R5MPWST.
L1207C1R5MPWST has an inductance value of 1.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L1207C1R5MPWST is rated for 860 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L1207C1R5MPWST lists a DC resistance of 70mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L1207C1R5MPWST uses a package or case of 1207 (3218 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L1207C1R5MPWST to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 860 mA |
| DC Resistance (DCR) | 70mOhm |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.126" L x 0.071" W (3.20mm x 1.80mm) |
| Case / Size | 1207 (3218 Metric) |
| Package / Case | 1207 (3218 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 1.5UH 860MA 70 MOHM |
| Series | L-PWS |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Self Resonant Frequency | 80MHz |
| Inductance Test Frequency | 7.96 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1207 |
| Height - Seated (Max) | 0.079" (2.00mm) |
