Description
FIXED IND 3.3UH 560MA 110 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L1207C3R3MPWST.
L1207C3R3MPWST has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L1207C3R3MPWST is rated for 560 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L1207C3R3MPWST lists a DC resistance of 110mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L1207C3R3MPWST uses a package or case of 1207 (3218 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L1207C3R3MPWST to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 560 mA |
| DC Resistance (DCR) | 110mOhm |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.126" L x 0.071" W (3.20mm x 1.80mm) |
| Case / Size | 1207 (3218 Metric) |
| Package / Case | 1207 (3218 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 3.3UH 560MA 110 MOHM |
| Series | L-PWS |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Self Resonant Frequency | 54MHz |
| Inductance Test Frequency | 7.96 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1207 |
| Height - Seated (Max) | 0.079" (2.00mm) |
