FIXED IND 4.7UH 4.3A 33 MOHM SMD
| Inductance | 4.7 µH |
| Tolerance | - |
| Current Rating | 4.3 A |
| DC Resistance (DCR) | 33mOhm |
| saturationCurrent | 5A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.193" L x 0.193" W (4.90mm x 4.90mm) |
| Case / Size | Nonstandard, 2 Lead |
| Supplier | Monolithic Power Systems Inc. |
| Description | FIXED IND 4.7UH 4.3A 33 MOHM SMD |
| Series | MPL-SE |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Semi-Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.157" (4.00mm) |
| features | - |
