FIXED IND 1.5UH 5.9A 21.7 MOHM
| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 5.9 A |
| DC Resistance (DCR) | 21.7mOhm Max |
| saturationCurrent | 5.6A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.217" L x 0.197" W (5.50mm x 5.00mm) |
| Case / Size | Nonstandard |
| Supplier | KEMET |
| Description | FIXED IND 1.5UH 5.9A 21.7 MOHM |
| Series | MPLCG |
| productStatus | Active |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Metal Composite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.118" (3.00mm) |
| features | Low DCR, Low Loss |
