Description
FIXED IND 220NH 19.4A 3.3 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPXV1D0624LR22.
MPXV1D0624LR22 has an inductance value of 220 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPXV1D0624LR22 is rated for 19.4 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPXV1D0624LR22 lists a DC resistance of 3.3mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPXV1D0624LR22 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPXV1D0624LR22 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 220 nH |
| Tolerance | ±20% |
| Current Rating | 19.4 A |
| DC Resistance (DCR) | 3.3mOhm Max |
| Saturation Current | 29A |
| Operating Temperature | -55°C ~ 155°C |
| Dimensions | 0.276" L x 0.256" W (7.00mm x 6.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | KEMET |
| Description | FIXED IND 220NH 19.4A 3.3 MOHM |
| Series | METCOM MPXV |
| Product Status | Active |
| Core Material | Metal Composite |
| Shielding | Shielded |
| Self Resonant Frequency | 120MHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.094" (2.40mm) |
