SPB1007-R27M
Bourns Inc.
- Inductance
- 270 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
Series: SPB1007
Browse series tables and compare the available specifications.
SPB1007
SPB1007-R17M
Bourns Inc.
- Inductance
- 175 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
SPB1007-R15M
Bourns Inc.
- Inductance
- 150 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
SPB1007-R30M
Bourns Inc.
- Inductance
- 300 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
SPB1007-R22M
Bourns Inc.
- Inductance
- 215 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
SPB1007-R23M
Bourns Inc.
- Inductance
- 230 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
SPB1007-R12M
Bourns Inc.
- Inductance
- 115 nH
- Current
- 61 A
- DCR
- 0.35mOhm Max
- Size
- 0.413" L x 0.315" W (10.50mm x 8.00mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
SPB1007-R27M Bourns Inc. | 270 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R17M Bourns Inc. | 175 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R15M Bourns Inc. | 150 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R30M Bourns Inc. | 300 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R22M Bourns Inc. | 215 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R23M Bourns Inc. | 230 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard | |
SPB1007-R12M Bourns Inc. | 115 nH | 61 A | 0.35mOhm Max | 0.413" L x 0.315" W (10.50mm x 8.00mm) | Nonstandard |
