MPL-AL4020-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 3.65 A
- DCR
- 52.2mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
Inductor Datasheets
Browse and download PDF datasheets for inductors from leading manufacturers.
139 datasheets found from Monolithic Power Systems Inc.
MPL-SE4030-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 6.3 A
- DCR
- 12.5mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE4030-100
Monolithic Power Systems Inc.
- Inductance
- 10 µH
- Current
- 2.2 A
- DCR
- 97mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE4030-330
Monolithic Power Systems Inc.
- Inductance
- 33 µH
- Current
- 1.1 A
- DCR
- 400mOhm Max
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-AT2512-R47
Monolithic Power Systems Inc.
- Inductance
- 470 nH
- Current
- 5.5 A
- DCR
- 19mOhm
- Size
- 0.098" L x 0.079" W (2.50mm x 2.00mm)
MPL-AT2512-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 2.8 A
- DCR
- 82mOhm Max
- Size
- 0.098" L x 0.079" W (2.50mm x 2.00mm)
MPL-AL4020-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 5.5 A
- DCR
- 21.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL4020-3R3
Monolithic Power Systems Inc.
- Inductance
- 3.3 µH
- Current
- 4.4 A
- DCR
- 34.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL5030-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 8.2 A
- DCR
- 12.3mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL5050-100
Monolithic Power Systems Inc.
- Inductance
- 10 µH
- Current
- 4.8 A
- DCR
- 37mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
MPL-AL6050-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 12 A
- DCR
- 8.3mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6050-3R3
Monolithic Power Systems Inc.
- Inductance
- 3.3 µH
- Current
- 10.1 A
- DCR
- 11.5mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6050-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 7.5 A
- DCR
- 16.5mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-AL6060-100
Monolithic Power Systems Inc.
- Inductance
- 10 µH
- Current
- 6.9 A
- DCR
- 24mOhm
- Size
- 0.260" L x 0.252" W (6.60mm x 6.40mm)
MPL-SE4030-2R2
Monolithic Power Systems Inc.
- Inductance
- 2.2 µH
- Current
- 3.9 A
- DCR
- 30mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE4030-3R3
Monolithic Power Systems Inc.
- Inductance
- 3.3 µH
- Current
- 3.45 A
- DCR
- 39.8mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE4030-150
Monolithic Power Systems Inc.
- Inductance
- 15 µH
- Current
- 1.6 A
- DCR
- 185mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE4030-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 2.6 A
- DCR
- 63mOhm
- Size
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
MPL-SE5040-4R7
Monolithic Power Systems Inc.
- Inductance
- 4.7 µH
- Current
- 4.3 A
- DCR
- 33mOhm
- Size
- 0.193" L x 0.193" W (4.90mm x 4.90mm)
MPL-SE5040-1R5
Monolithic Power Systems Inc.
- Inductance
- 1.5 µH
- Current
- 6.2 A
- DCR
- 14mOhm
- Size
- 0.193" L x 0.193" W (4.90mm x 4.90mm)
MPL-AT2010-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 3.2 A
- DCR
- 50mOhm
- Size
- 0.079" L x 0.063" W (2.00mm x 1.60mm)
MPL-AT2512-1R0
Monolithic Power Systems Inc.
- Inductance
- 1 µH
- Current
- 4 A
- DCR
- 35mOhm
- Size
- 0.098" L x 0.079" W (2.50mm x 2.00mm)
MPL-AY3020-1R5
Monolithic Power Systems Inc.
- Inductance
- 1.5 µH
- Current
- 3.4 A
- DCR
- 35mOhm
- Size
- 0.138" L x 0.126" W (3.50mm x 3.20mm)
MPL-AL4020-R68
Monolithic Power Systems Inc.
- Inductance
- 680 nH
- Current
- 8.7 A
- DCR
- 7.5mOhm
- Size
- 0.161" L x 0.161" W (4.10mm x 4.10mm)
MPL-AL5050-8R2
Monolithic Power Systems Inc.
- Inductance
- 8.2 µH
- Current
- 5.8 A
- DCR
- 28mOhm
- Size
- 0.217" L x 0.209" W (5.50mm x 5.30mm)
| Product | Inductance | Current | DCR | Size | Package | Actions |
|---|---|---|---|---|---|---|
MPL-AL4020-4R7 Monolithic Power Systems Inc. | 4.7 µH | 3.65 A | 52.2mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-SE4030-1R0 Monolithic Power Systems Inc. | 1 µH | 6.3 A | 12.5mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE4030-100 Monolithic Power Systems Inc. | 10 µH | 2.2 A | 97mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE4030-330 Monolithic Power Systems Inc. | 33 µH | 1.1 A | 400mOhm Max | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 1616 (4040 Metric) | |
MPL-AT2512-R47 Monolithic Power Systems Inc. | 470 nH | 5.5 A | 19mOhm | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 2-SMD, J-Lead | |
MPL-AT2512-2R2 Monolithic Power Systems Inc. | 2.2 µH | 2.8 A | 82mOhm Max | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 1008 (2520 Metric) | |
MPL-AL4020-2R2 Monolithic Power Systems Inc. | 2.2 µH | 5.5 A | 21.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL4020-3R3 Monolithic Power Systems Inc. | 3.3 µH | 4.4 A | 34.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL5030-2R2 Monolithic Power Systems Inc. | 2.2 µH | 8.2 A | 12.3mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL5050-100 Monolithic Power Systems Inc. | 10 µH | 4.8 A | 37mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD | |
MPL-AL6050-2R2 Monolithic Power Systems Inc. | 2.2 µH | 12 A | 8.3mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6050-3R3 Monolithic Power Systems Inc. | 3.3 µH | 10.1 A | 11.5mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6050-4R7 Monolithic Power Systems Inc. | 4.7 µH | 7.5 A | 16.5mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-AL6060-100 Monolithic Power Systems Inc. | 10 µH | 6.9 A | 24mOhm | 0.260" L x 0.252" W (6.60mm x 6.40mm) | 2-SMD | |
MPL-SE4030-2R2 Monolithic Power Systems Inc. | 2.2 µH | 3.9 A | 30mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE4030-3R3 Monolithic Power Systems Inc. | 3.3 µH | 3.45 A | 39.8mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE4030-150 Monolithic Power Systems Inc. | 15 µH | 1.6 A | 185mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE4030-4R7 Monolithic Power Systems Inc. | 4.7 µH | 2.6 A | 63mOhm | 0.157" L x 0.157" W (4.00mm x 4.00mm) | Nonstandard, 2 Lead | |
MPL-SE5040-4R7 Monolithic Power Systems Inc. | 4.7 µH | 4.3 A | 33mOhm | 0.193" L x 0.193" W (4.90mm x 4.90mm) | Nonstandard, 2 Lead | |
MPL-SE5040-1R5 Monolithic Power Systems Inc. | 1.5 µH | 6.2 A | 14mOhm | 0.193" L x 0.193" W (4.90mm x 4.90mm) | Nonstandard, 2 Lead | |
MPL-AT2010-1R0 Monolithic Power Systems Inc. | 1 µH | 3.2 A | 50mOhm | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 2-SMD, J-Lead | |
MPL-AT2512-1R0 Monolithic Power Systems Inc. | 1 µH | 4 A | 35mOhm | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 2-SMD, J-Lead | |
MPL-AY3020-1R5 Monolithic Power Systems Inc. | 1.5 µH | 3.4 A | 35mOhm | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 2-SMD, J-Lead | |
MPL-AL4020-R68 Monolithic Power Systems Inc. | 680 nH | 8.7 A | 7.5mOhm | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 2-SMD | |
MPL-AL5050-8R2 Monolithic Power Systems Inc. | 8.2 µH | 5.8 A | 28mOhm | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 2-SMD |
