L0805B220MDWLT
KEMET
0805 (2012 Metric)
Description
FIXED IND 22UH SURFACE MOUNT
Specifications
Inductance
22 µH
Dimensions
0.079" L x 0.049" W (2.00mm x 1.25mm)
Parameter Guide
Understand the key electrical and mechanical specifications for L0805B220MDWLT.
Inductance
22 µH
L0805B220MDWLT has an inductance value of 22 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
Package / Case
0805 (2012 Metric)
L0805B220MDWLT uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0805B220MDWLT to manufacturer, series, and broader datasheet collections.
Product Attributes
Datasheet record
Last updated: 7/5/2026| Inductance | 22 µH |
| Tolerance | ±20% |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | KEMET |
| Description | FIXED IND 22UH SURFACE MOUNT |
| Series | L-DWL |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0805 (2012 Metric) |
| Height - Seated (Max) | 0.057" (1.45mm) |
