Description
FIXED IND 450NH 25A 1.1 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPC1040LR45C.
MPC1040LR45C has an inductance value of 450 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPC1040LR45C is rated for 25 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPC1040LR45C lists a DC resistance of 1.1mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPC1040LR45C uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPC1040LR45C to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 450 nH |
| Tolerance | ±20% |
| Current Rating | 25 A |
| DC Resistance (DCR) | 1.1mOhm Max |
| Saturation Current | 27A |
| Operating Temperature | -20°C ~ 120°C |
| Dimensions | 0.453" L x 0.394" W (11.50mm x 10.00mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | KEMET |
| Description | FIXED IND 450NH 25A 1.1 MOHM SMD |
| Series | MPC |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.157" (4.00mm) |
| Features | - |
