Description
FIXED IND 4.7UH 11.5A 9.5 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPL-AY1050-4R7.
MPL-AY1050-4R7 has an inductance value of 4.7 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPL-AY1050-4R7 is rated for 11.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPL-AY1050-4R7 lists a DC resistance of 9.5mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPL-AY1050-4R7 uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPL-AY1050-4R7 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 4.7 µH |
| Tolerance | - |
| Current Rating | 11.5 A |
| DC Resistance (DCR) | 9.5mOhm |
| Saturation Current | 15A |
| Operating Temperature | -40°C ~ 155°C |
| Dimensions | 0.433" L x 0.394" W (11.00mm x 10.00mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Monolithic Power Systems Inc. |
| Description | FIXED IND 4.7UH 11.5A 9.5 MOHM |
| Series | MPL-AY |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Features | - |
