Description
FIXED IND 1UH 7.6A 9.4 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPL-SE5040-1R0.
MPL-SE5040-1R0 has an inductance value of 1 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPL-SE5040-1R0 is rated for 7.6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPL-SE5040-1R0 lists a DC resistance of 9.4mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPL-SE5040-1R0 uses a package or case of Nonstandard, 2 Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPL-SE5040-1R0 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 1 µH |
| Current Rating | 7.6 A |
| DC Resistance (DCR) | 9.4mOhm |
| Saturation Current | 10.5A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.193" L x 0.193" W (4.90mm x 4.90mm) |
| Case / Size | Nonstandard, 2 Lead |
| Package / Case | Nonstandard, 2 Lead |
| Supplier | Monolithic Power Systems Inc. |
| Description | FIXED IND 1UH 7.6A 9.4 MOHM SMD |
| Series | MPL-SE |
| Product Status | Active |
| Shielding | Semi-Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.157" (4.00mm) |
