Description
FIXED IND 1.5UH 12.4A 7 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPLC1040L1R5.
MPLC1040L1R5 has an inductance value of 1.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPLC1040L1R5 is rated for 12.4 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPLC1040L1R5 lists a DC resistance of 7mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPLC1040L1R5 uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPLC1040L1R5 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 12.4 A |
| DC Resistance (DCR) | 7mOhm Max |
| Saturation Current | 12.7A |
| Operating Temperature | -20°C ~ 120°C |
| Dimensions | 0.453" L x 0.394" W (11.50mm x 10.00mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | WEC,KEMET |
| Description | FIXED IND 1.5UH 12.4A 7 MOHM SMD |
| Series | MPLC |
| Product Status | Obsolete |
| Type / Construction | Wirewound |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.157" (4.00mm) |
| Features | - |
