Description
FIXED IND 680NH 7.9A 11.6 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MPLCG0530LR68.
MPLCG0530LR68 has an inductance value of 680 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MPLCG0530LR68 is rated for 7.9 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MPLCG0530LR68 lists a DC resistance of 11.6mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MPLCG0530LR68 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MPLCG0530LR68 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 680 nH |
| Tolerance | ±20% |
| Current Rating | 7.9 A |
| DC Resistance (DCR) | 11.6mOhm Max |
| Saturation Current | 6.8A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.217" L x 0.197" W (5.50mm x 5.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | KEMET |
| Description | FIXED IND 680NH 7.9A 11.6 MOHM |
| Series | MPLCG |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Metal Composite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Features | Low DCR, Low Loss |
