Description
FIXED IND 219UH 15A 19.5 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SHBC24N-2R0A0219V.
SHBC24N-2R0A0219V has an inductance value of 219 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SHBC24N-2R0A0219V is rated for 15 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SHBC24N-2R0A0219V lists a DC resistance of 19.5mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SHBC24N-2R0A0219V uses a package or case of Radial, Vertical (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SHBC24N-2R0A0219V to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 219 µH |
| Tolerance | ±20% |
| Current Rating | 15 A |
| DC Resistance (DCR) | 19.5mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 1.988" Dia (50.50mm) |
| Case / Size | Radial, Vertical (Open) |
| Package / Case | Radial, Vertical (Open) |
| Supplier | KEMET |
| Description | FIXED IND 219UH 15A 19.5 MOHM TH |
| Series | SHBC |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Alloy Powder |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 1.988" (50.50mm) |
| Features | - |
