Description
FIXED IND 174UH 20A 11.8 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for SHBC24W-2R4A0174V.
SHBC24W-2R4A0174V has an inductance value of 174 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
SHBC24W-2R4A0174V is rated for 20 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
SHBC24W-2R4A0174V lists a DC resistance of 11.8mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
SHBC24W-2R4A0174V uses a package or case of Radial, Vertical (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from SHBC24W-2R4A0174V to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 174 µH |
| Tolerance | ±20% |
| Current Rating | 20 A |
| DC Resistance (DCR) | 11.8mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 2.268" Dia (57.60mm) |
| Case / Size | Radial, Vertical (Open) |
| Package / Case | Radial, Vertical (Open) |
| Supplier | KEMET |
| Description | FIXED IND 174UH 20A 11.8 MOHM TH |
| Series | SHBC |
| Product Status | Active |
| Type / Construction | Toroidal |
| Core Material | Alloy Powder |
| Shielding | Unshielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 2.268" (57.60mm) |
| Features | - |
